metal parts kovar cnc machining

Kovar CNC Machining

XTJ Precision Mfg crafts precision Kovar alloy parts with unmatched expertise, tailored to your toughest project demands.

This image provides an overview of the XTJ Precision Mfg CNC machining production workshop. It showcases the advanced equipment and organized workspace dedicated to precision manufacturing processes.

Your Trusted Partner for Kovar CNC Machining

Need Kovar alloy parts that perform flawlessly in aerospace or electronics?
XTJ Precision Mfg, an ISO 9001 certified manufacturer, brings over 20 years of expertise to deliver custom Kovar components with tolerances as tight as ±0.002 mm. Our advanced 3-, 4-, and 5-axis CNC machining, combined with Electrical Discharge Machining (EDM), ensures precision for even the most complex designs. From rapid prototypes to high-volume production, we offer tailored solutions with finishes like passivation or electroplating to boost durability and performance. Let’s turn your ideas into reality!

What is Kovar Alloy?

Kovar, or ASTM F15, is a nickel-cobalt-iron alloy prized for its thermal expansion properties that closely match those of borosilicate glass and ceramics. Composed of approximately 29% nickel, 17% cobalt, and 54% iron, with trace elements like manganese and silicon, Kovar ensures reliable hermetic seals across a wide temperature range (-80°F to 450°F). Its stability and machinability make it a top choice for precision components in electronics, aerospace, and medical applications.

Element Percent by Weight Function in Alloy
Nickel (Ni) 29% Controls thermal expansion, improves corrosion resistance
Cobalt (Co) 17% Enhances thermal stability, adds strength
Iron (Fe) ~54% Forms the alloy base, affects magnetic properties
Silicon (Si) ~0.2% Improves melt quality, reduces oxidation
Manganese (Mn) ~0.5% Improves melt quality, reduces oxidation
Carbon (C) ~0.02% Refines grain structure, enhances strength

Expert Kovar Alloy Machining at XTJ Precision Mfg

Kovar’s properties require specialized machining to achieve precision. XTJ employs the following techniques:

EDM Machining of kovar alloy

Electrical Discharge Machining (EDM)

Non-contact method for complex shapes, minimizing stress and maintaining material integrity with fine finishes.

Kovar CNC Machining services

CNC Machining

Using 3-, 4-, and 5-axis CNC machines with carbide tools for intricate designs and tight tolerances, optimized for Kovar’s work-hardening nature.

Kovar Alloy Parts Manufactured via Laser Cutting

Laser Cutting

Precise cuts with minimal heat-affected zones, ideal for intricate patterns and high repeatability.

Specialized Cutting Tools for Kovar Alloy Machining

Tooling Requirements

Sharp carbide or diamond-coated tools with optimized edge angles (>25°) to reduce work-hardening and ensure clean cuts.

Design Tips for Kovar CNC Machining

To maximize Kovar’s performance, consider these design and machining strategies:

Match Thermal Expansion

Align Kovar’s CTE with adjacent materials to prevent stress during temperature changes.

Optimize Speeds and Feeds

Use lower speeds and higher feeds to minimize work-hardening and maintain precision.

Use Carbide Tools

Employ hard-tipped tools to withstand Kovar’s abrasiveness and extend tool life.

Pre- and Post-Annealing

Anneal before machining to relieve stresses and after to ensure dimensional stability.

Surface Finishing

Apply passivation or electroplating to enhance corrosion resistance and solderability.

Industries Served by Kovar CNC Machining

XTJ’s Kovar machining expertise powers industries that demand precision and performance

  • Electronics: Hermetic seals for microchips, diodes, and semiconductor packaging.
  • Aerospace: Components for satellites and aircraft that endure extreme temperatures.
  • Medical: Nonmagnetic parts for MRI machines and biocompatible implants.
  • Telecommunications: Shielded components for reliable high-frequency signal transmission.
  • Optics & Scientific: Precision parts for lasers and measurement instruments.

Performance Features of Kovar for CNC Machining

Kovar’s unique properties make it ideal for precision applications where reliability is non-negotiable. Here’s why it’s a top pick:

  • Thermal Expansion Match: Aligns with glass and ceramics for secure hermetic seals in temperature-varying environments.
  • Dimensional Precision: Maintains stability for critical components in electronics and optics.
  • Low Magnetic Interference: Controlled permeability ensures minimal disruption in sensitive devices.
  • Machinability: Supports complex geometries and tight tolerances with advanced CNC techniques.
  • Corrosion Resistance: Resists oxidation, ensuring durability in harsh conditions.
  • Reliable Sealing: Creates airtight seals to protect electronics from moisture and contaminants.

How Kovar Compares to Other Metals

Kovar stands out for its unique properties, but how does it stack up against other metals? Here’s a comparison to help you choose the right material:

Property

Kovar Alloy

Aluminum

Stainless Steel

Copper

Titanium

Composition

Fe-Ni-Co alloy

Al

Fe-Cr-Ni (varies)

Cu

Ti

Thermal Expansion (ppm/°C)

4.6–5.4 (at 30°C)

23.1

17.3

16.5

8.6

Machinability

Moderate (special tools)

High

Moderate

High

Low

Magnetic Properties

Magnetic

Non-magnetic

Usually non-magnetic

Non-magnetic

Non-magnetic

Corrosion Resistance

Good

Excellent

Excellent

Good

Excellent

Cost

Higher

Lower

Moderate

Moderate

Higher

Which industries use XTJ’s Kovar machining?

We serve electronics, aerospace, medical, telecommunications, and optics with precision Kovar components.

Which industries use XTJ’s Kovar machining?

We serve electronics, aerospace, medical, telecommunications, and optics with precision Kovar components.

How does XTJ handle Kovar’s machining challenges?

We use carbide tools, high-pressure coolants, and precise CNC programming to manage work-hardening and heat buildup.

Can XTJ deliver tight tolerances for Kovar parts?

Yes, our 5-axis CNC and EDM achieve tolerances as tight as ±0.002 mm for demanding applications.

How fast can I get a Kovar prototype?

We offer rapid prototyping with lead times as short as 3 days, tailored to your project’s complexity.

Frequently Asked Questions

Ready to Start Your Kovar CNC Machining Project?

Upload your design for a free quote or connect with our team to discuss your needs.
